| Video Input | |
| Interfaces | 1 x HDMI Type A Female |
| Video Output | |
| Interfaces | 12 x DisplayPort 1.1 Female |
| Video | |
| Max. Data Rate | 8.64 Gbps (2.7 Gbps per lane) |
| Max. Pixel Clock | 340 MHz (with DP to DVI active adapter) |
| Compliance | HDMI (3D, Deep Color) DisplayPort 1.1 |
| Audio | |
| Output | 1 x 3.5 mm Stereo Jack Female |
| Control | |
| RS-232 | Connector: 2 x DB-9 Female (Black) Baud Rate and Protocol: Baud Rate: 38400~19200, Hardware & Software Flow Control *RS-232 functionality is pending and will be available with future firmware upgrades |
| Ethernet | 2 x RJ-45 Female |
| USB | 2 x USB 3.0 Female 4 x USB 2.0 Female |
| Connectors | |
| Power | 1 x 3-prong AC Socket |
| Power | |
| Maximum Input Power Rating | 100-240 VAC; 50-60 Hz; 3A |
| Power Consumption | 120 VAC, 400W; 230 VAC, 400W |
| Fan | Airflow: 28.8 cfm (max. in free air) Operating voltage: 6.0 ~ 12.0 VDC Operating temp: -10 ~ 65 ºC |
| Storage Capacity | 64GB mSATA |
| System Memory | 8GB DDR3 |
| Environmental | |
| Operating Temperature | 0-40°C |
| Storage Temperature | -20 – 60°C |
| Humidity | 0 – 80% RH, Non-Condensing |
| Physical Properties | |
| Housing | Metal |
| Weight | 4.22 kg ( 9.3 lb ) |
| Dimensions (L x W x H) | 43.00 x 27.00 x 4.40 cm (16.93 x 10.63 x 1.73 in.) |
| Carton Lot | 3 pcs |
| Note | For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format. |
